Mosconi Pro 4|30
4 channel high performance amplifier
4 channel amplifier
Class A-AB technology
Up to 4 x 225 Watts @ 2 Ohm
Filippo Kania's masterpiece. (chief developer Mosconi)
The MOSCONI PRO 4|30 is a high-end 4-channel amplifier with a new Advanced AA/B amplifier technology. With this revolutionary AA/B circuit, the PRO 4|30 runs up to 30 Watts RMS in pure Class A mode and spoils the listener with everything that makes a Class A amplifier: airy, fine, rich in detail with an incredible amount of space.
With the combination of an extremely open, finely drawn sound image and its unique naturalness, the PRO 4|30 inspires music from the very first beat.
When performance and headroom are required, it packs a punch with 170 Watts RMS (at 4 Ohm) per channel (450 W bridged).
Output Power
Output power @ 4Ω: 4 x 170 Watts
Output power @ 2Ω: 4 x 225 Watts
Bridged Output power @ 4Ω: 2 x 450 Watts
Specifications
Input sensitivity: 0.35 V ÷ 12 V (5.3 V in DDSP mode) [CH 1/2/3/4]
Dimensions: 500 x 205 x 55 mm
Weight: 5,1 kg
Crossover:
CH 1/2 = HP: 43 ÷ 500 Hz (x 1) or 430 ÷ 5000 Hz (x 10)
CH 3/4 = HP: 18 ÷ 220 Hz & LP: 43 ÷ 500 Hz
Signal to Noise Ratio: > 83 dBA (ref: 1 Watt into 4 Ohm)
